PM-P140 THERMISTOR TEMPERATURE TRANSDUCER TRAINER

PM-P140 THERMISTOR TEMPERATURE TRANSDUCER TRAINER Description: SCOPE OF LEARNING: Study of THERMISTOR as Temperature Measuring Transducer  TECHNICAL SPECIFICATIONS: Digital Meters: Voltmeter 200mV DC. Power Supplies: DC Supply IC Regulated  + 12V, +5V DC, 150mA. Operated on Mains power 230V, 50Hz  + 10% Components are mounted on the panels are: Thermistor Variable Resistor 741 IC Electrical Kettle as Heating Element. Thermometer SALIENT   FEATURES: Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols. Fuse for Short Circuit protection Instruction manual. Connections are brought out through 2mm Colored Sockets. Patch Cords 2mm. The trainer is housed in ABS Plastic cabinet. Size of the trainer set 12”x8” OPTIONAL ACCESSORIES: Multimeter Digital Thermometer Conclusion Now we have seen above the details of about   PM-P140 THERMISTOR TEMPERATURE TRANSDUCER TRAINER Regards Shr...
Post a Comment

PM-P018 HARTLEY OSCILLATOR TRAINER

PM-P018 HARTLEY OSCILLATOR TRAINER

PM-P018 HARTLEY OSCILLATOR TRAINER


Description:

SCOPE OF LEARNING:

  • Study and Construction of Hartley Oscillator
  • TECHNICAL SPECIFICATIONS:

Power Supplies:

  • DC Power Supply IC Regulated +15V DC, 150mA.
    • Operated on Mains power 230V, 50Hz +10%

Components are mounted on the panels are:

  • Transistor 2N2222
  • Resistors
  • Capacitors
  • Inductor

Output Performance Approximate

  •   HARTLEY: 1MHZ,304KHZ

SALIENT FEATURES:

  • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
    • Fuse for Short Circuit protection
    • Instruction manual.
    • Connections are brought out through 4mm Colored Sockets.
    • Patch Cords 4mm.
    • The trainer is housed in ABS Plastic cabinet.
    • Size of the trainer set 10”x8”

OPTIONAL ACCESSORIES:

  • CRO

Conclusion

Now we have seen above the details of about  PM-P018 HARTLEY OSCILLATOR TRAINER

Regards

Shrawan Malviya (Director)

Mob: 9825568628

Website: P M Enterprise



Location: India

Comments

Post a Comment
